Product Description

Mobile air conditioning solutions

Description

The mobile air-conditioning solution launched by Golden Triangle Group is composed of a highly sensitive, highly anti-interference touch control panel and a high-precision temperature detection motherboard. The built-in LED module, touch module and communication module (including UART/IIC protocol) in the chip greatly improve the efficiency of development and simplify the circuit. Excellent EMC performance improves the stability and reliability of the solution.

Mobile air conditioning program performance characteristics:

> The solution has excellent EMC performance, easy to pass CS dynamic and static 10V

> High-sensitivity, high-disturbance touch hardware design and supporting software algorithms

> Equipped with common modules such as LED, TOUCH, UART, etc. to reduce the difficulty of development

> Adopt high-precision 12bit ADC to provide guarantee for accurate temperature detection and control

> Using 16bitPWM, frequency conversion control is smoother and higher precision

> All digital functions can be configured on any GPIO, and all GPIO support configuration as ADC channels, which is convenient for circuit design

> Equipped with BOOT area settings to facilitate remote upgrade of the program

Attribute	Attribute Value
EMC performance	Excellent EMC performance
CS test	Easily passes the CS dynamic and static 10V test
Touch hardware design	High-sensitivity, high-disturbance touch hardware design
Touch software algorithms	Supporting software algorithms for touch
Common modules	Equipped with common modules such as LED, TOUCH, UART
ADC precision	High-precision 12-bit ADC for accurate temperature detection and control
PWM control	Uses 16-bit PWM for smoother and higher precision frequency conversion control
GPIO flexibility	All digital functions can be configured on any GPIO
GPIO configuration	All GPIO support configuration as ADC channels
Remote program upgrade	Equipped with BOOT area settings for remote program upgrades

System diagram
